Creating custom routes in Azure Functions

I’ve been working on my URL shortener project recently, but I took a few days away from it to start writing some JavaDoc for the Java APIs for Azure Functions. In doing so I learned about a cool piece of API that might not be readily apparent (although I hope it is now that I’ve written documentation!), and so in this blog post I wanted to quickly introduce the route field on the @HttpTrigger annotation.

By default, when you create a function for an HTTP trigger the function is addressable with a route of the form http://<yourapp><functionname>. This is fine in many cases, but in some cases you want your endpoint to be parameterised. For example, we’ve all seen URLs such as, where the java can be replaced by any value (I hope I’m not shattering illusions for anyone by informing you that these all aren’t separate HTML pages sitting on a server 🙂 ). Doing this with Azure Functions is trivial, with help from the route property. For example, we could specify a route of products/{category:alpha}/{id:int}, and this would mean that the function is now addressable at http://<yourapp>

If the only benefit was that the path was parameterised, we wouldn’t bother using this API, which is why the other half of the feature is the ability to use the @BindingName annotation to bring in these arguments into the function. For example, here is a full method signature with route and @BindingName in use (apologies for the odd line wrapping required):

As can be seen here, we are receiving the category and id values from the URL endpoint and they are being provided to us as arguments into the function itself, where they are immediately usable. The route string can be quite complex, as there are a number of configuration options available. Microsoft has published useful documentation on routing (just ignore the C# noise 🙂 ).

This has just been a quick blog post on the routing support in Azure Functions, because I thought it was neat. I will keep posting this short snippets as I discover API that delights me. As always though: playing with Azure Functions is really fun – I recommend all Java developers take it for a spin to see what they can achieve when they don’t need to worry about all the underlying infrastructure. Even better, you can get started with the free tier where you have 1,000,000 free function calls a month, and go from there! If you want more inspiration, check out my series on URL shorteners, built using Java and Azure Functions.

Building a serverless url shortener with Azure Functions and Java, part one

I’m a Java engineer who doesn’t really know the intricacies of cloud development as well as my ‘Cloud Developer Advocate‘ job title suggests that I should. That is why I’m such a fan of Azure Functions – it makes the concept of serverless programming a possibility for Java developers. Serverless is one of those odd marketing terms, but what it essentially boils down to, as my colleague Jeremy Likness likes to say, is that it is ‘less server’ – which sounds perfect for me! 🙂

To better understand Azure Functions, I set out to build a URL shortener app, so that I could take a long URL like and replace it with a short url like I’m not the first Microsoft Cloud Developer Advocate to do this, as it seems like one of those projects people like to do when they first encounter serverless programming 🙂 You can read Jeremy’s blog about how he built a URL shortener in C# (he’s put a lot more hours into features than me, so there is a lot of good ideas there to borrow 🙂 ).

This is a first post in a series. I’ll add links here when I publish new articles, but you can always follow me on Twitter to keep updated.

Serverless Value Proposition

The main attraction to building a link shortener using serverless programming is that you only pay for the time your function is actually operating – you aren’t paying for 24/7/365 server uptime, which is pretty handy for a link shortener that only operates occasionally. You also don’t need to worry at all about concerns such as scaling your service – the cloud provider takes care of that for you. I wanted to build this as cheaply as possible (i.e. consume as few resources, and use the cheapest options) in Microsoft Azure, and I didn’t want to have to write code in any language other than Java, and I really didn’t want to have to worry about all that other cloud nonsense 🙂

In terms of actual costs, Jeremy stated in his blog post the following:

Although actual results will differ for everyone, in my experience, running the site for a week while generating around 1,000 requests per day resulted in a massive seven cent U.S.D. charge to my bill. I don’t think I’ll have any problem affording this!

He also updated his calculations for cost in a follow-up tweet:

I tend to agree – I think I can afford this serverless lifestyle! 🙂 So, off I set on my adventure… I started by buying two domain names – and – which both seemed relevant to my interests. After that, I started writing code (and note: this project is all open source on GitHub)! 🙂 Let’s get into it…

Creating a Java Function App

Setting up a new Azure Function App is simple, especially with the Java / Maven tooling that is available. Firstly though, if you don’t have an Azure account, you can create one for free, and it comes with 1,000,000 Azure Function calls free per month forever (which is well in excess of what I need, so I don’t think I’ll even be spending 7 cents)! Once you have an account, you can follow the Azure Functions on Java tutorial to step through the software setup and creating your own function app. The approach works really smoothly – it’s all based around a few Maven commands that will auto-generate your first function, and you even use this to deploy to Azure! Because of this, I’m not going to dive any more deeply into getting started with Azure Functions with Java, and I’m just going to dive into some of the configuration details, and then into the code for building a link shortener.

Once you’ve done your first mvn clean package azure-functions:deploy, you can log in to the Azure Portal to see your function app, which will look something like this:

In here you’ll see a list of your functions in the left column (my app has four functions: frontend, keepAlive, redirect, and shortcode, as well as details on the URL, subscription, etc. Today we will just discuss the redirect and shortcode functions, and address the other two functions in another blog post.

By default, to access any of your functions, you simply take the base URL (in the image above, it is, add /api/, and then the function name. For example, the redirect function is at (and, low-and-behold, if you go there with a given shortcode, it should work – try As noted at the beginning of this post, the final URL is, but that is achieved using an Azure Functions Proxy, which simply redirects to the full URL shown here. We will return to proxy configuration in a later blog post, to achieve this nicer URL effect.

URL Shortening Function

The key requirement of a URL shortener is to take a URL and return a shorter URL. In terms of implementation, it’s quite simple really – take a url query parameter that we want to convert, use some algorithm to create a unique short code, and store it in some persistent storage. That is basically what you see in the code below, with one additional feature: the shortcode function also supports an optional shortcode parameter. If the user specifies a preferred shortcode (like ‘docs’ above), we simply store that mapping in the persistent storage without running the shortcode algorithm. Here’s essentially the full code listing (remember all the code is on GitHub):

As can be seen, at present there is no authentication, so anyone can create shortlinks (I might rectify this some day soon) 🙂 We simply check the url is valid, and if the user wants an auto-generated shortcode or if they want to provide their own. Based on this, we go in to one of two functions. In the auto-generated case, we iterate until we find an acceptable shortcode, and then we persist that into the data store.

In terms of data storage, I’ve written a small wrapper API around the Azure Storage APIs for Java, as I originally intended to use MySQL or SQL Server (with or without JPA), but then I realised that because Azure Functions are built on top of Azure App Service, which has built-in storage available to it. Because of this, I simply piggy-back on the table store that is already available, using the Java APIs explained in the Azure Table Storage guide. I’ve written a simple AzureTableStore class to handle the read / write access to this table:

The end result of all this code is that I have a table that shows all mappings. Here is a screenshot of the excellent (and free) Microsoft Azure Storage Explorer app, looking at my table of short codes (click the image for a larger version):

You can see I simply use the first letter of the RowKey as the PartitionKey, to have an even distribution in all partition buckets. You can also see that of the four short links I have created, two are ‘custom’ shortlinks (for docs and linkedin), and two are auto-generated (00 and zC). To generate the short links, I simply have the following code I use:

Again, it’s not the prettiest or best approach, but it’ll do for now 🙂

The end result of all this code is that a short code is generated, and a short url is returned, including the URL (that is, or, depending on which host was called to shrink the URL in the first place). That’s great, but it is only half the story – now we need to support the user actually going to that URL and it being converted to the long URL again!

Shortcode Redirection Function

The code to convert a shortcode into a full URL is even simpler, it simply gets the shortcode query parameter, looks up the long url in the data store, and does a HTTP 302 redirect to that URL (302 is the status code for a permanent redirect, as opposed to 301 which is temporary, and will therefore put more strain on the function for people who repeatedly visit the same URL). Here’s the redirect function class in full:

The only odd code is the line where I retrieve the url by calling Util.trackDependency(..). This code is simply convenience code that allows for me to more easily track application performance using Azure Application Insights, which I will cover in more detail in another blog. However, here’s the complete function listing, to make it clear that all that really is happening is we’re calling the data store to get the long url, and we’re recording how long it takes into Application Insights:


This is the core of the URL shortener, but there is a lot more still to cover, which I will cover in follow-up posts in the coming weeks. Topics I want to cover include:

  • Part two: Using queues and integrating realtime Slack notifications of events
  • Part three: Integrating Application Insights to learn more about performance bottlenecks, etc
  • Part four: Configuring proxies and custom domains
  • Part five: Building a static HTML user interface to easily create short links, and hosting it as an Azure Function
  • Part six: Focusing on performance – lets pay as little as possible by making our code as performant as possible

The main point for this post is that even though I’m not super-skilled in cloud development I was able to implement a simple application that provides a useful service to me, and at an extremely low cost. As I noted at the beginning, the cost to operate this service is mere cents per month! So, if you are a Java developer looking to build web services and don’t want to get bogged down in dealing with server details, you should definitely take a look at Azure Functions today – get started with the free tier and go from there!

Java desktop links of the week, March 12

Howdy folks! Big news this week, so let’s just get into it.

  • The big news this week was the announcement by Oracle that JavaFX is to be removed from the JDK from 11 onwards. This was covered in InfoWorld, and in a blog post and white paper by Oracle. In addition to JavaFX being moved to a module that is not shipped with the JDK, there were other Java client announcements made at the same time: Java Web Start and Applet technologies will also be removed from JDK 11 and future releases, and Swing / AWT, being a part of the Java SE spec, will continue to be supported through to 2026. For those of you forgetting the new release plan, JDK 11 is scheduled for release in September of this year. I have received a huge number of emails from people wondering what this means for JavaFX. The answer is – it is now in the hands of the community, with companies like Gluon stepping up to take on the load. You can choose to look at this optimistically (faster releases, easier contributions from community, etc) or cynically (another area that Oracle has abandoned and left the community in charge) – for me, I will write a blog post adding more detail about this as soon as possible.
  • Eric Canull has posted code to GitHub for a JavaFX-based sorting animation app.
  • Pedro Duque Vieira has updated his FXRibbon project to clean up API, etc.
  • Christoph Nahr has posted about Windows GUI DPI scaling in 2018.

Build Spring Boot 2.0 apps with Azure Starters and new VS Code extensions

I’ve said it elsewhere but my new role at Microsoft often places me at the end of a very powerful firehose, and I see a lot of cool stuff going by! Today is no exception – Microsoft has announced full support for Spring Boot 2.0 in the Spring Boot Starters for Azure. In addition to this, there is an updated Spring extension for Visual Studio Code, which allows you to build production-ready apps and easily deploy them to the cloud.
For more details, you should check out the blog post by Yitao Dong.

Java Engineering at Microsoft: Interview with Reiley Yang

Today I have another post in my Java / Azure interview series, this time with Reiley Yang. I met Reiley recently as we were both visiting the Microsoft Shanghai offices at the same time, and I learned more about what he is doing in the area of remote Java debugging with Azure. So, please, enjoy! 🙂

Hi Reiley – can you please introduce yourself to everyone?
Hey, I’m Reiley Yang. I started my career 12 years ago as a C/C++ developer (working on the low level stuff, C Runtime Libraries, compilers, debuggers, etc.), and later worked on different technologies and platforms. My hobbies include working on personal IoT projects, piano playing, woodwork, yard work, and cooking.

You and I met each other recently when we were in Shanghai at the same time, but you’ve been based out of Microsoft HQ in Redmond for some time now. You said you moved from Shanghai partially because you’re a keen piano player but couldn’t easily play piano in Shanghai without annoying your neighbours. Now that you have a bit more space in Redmond, I wondered if any of your piano music was recorded and online?
I do have some recordings, more for myself when I try to see what can be improved, I never published them though. I am a big fan of Chopin and J.S. Bach’s keyboard music. I hope that one day I could play all their works 🙂

When did you start working at Microsoft?
I started in 2006, then quit and worked in a start-up company, and re-joined Microsoft in 2011.

If I recall correctly you previously worked on C++ compilers and the like, and today you find yourself working on Java debugging on Azure. That’s quite a big change! Could you talk more about what you do at Microsoft today, and how you came to be working on Java at Microsoft?
Sure! I started working on the C++ runtime libraries and compilers. Later there was a need to improve the C++ / CLI debugger, which requires knowledge and experience from compiler, so I started to work on debuggers. Since then I’m always connected with debuggers and debugging.

There has been a long history between Microsoft and Java, and Microsoft was not doing well in the Java area in the early years. Now we have put tremendous amount of effort into making Microsoft technologies available for Java developers, and we want Microsoft tools and services to stand out in terms of Java support.

Debugging services in the cloud is hard, we’re experimenting with cloud debugging support for Java, and will add other language support in the future. Here’s a diagram outlining how things go together (click to see a bigger version):

As I understand it, remote debugging is still a proof of concept and you’re still seeking community feedback. How should developers test this functionality, and how should they provide feedback?
We have documented the steps, which explains the steps to debug Java-based Azure Functions in the cloud, and we use GitHub to track issues and collect suggestions.

The scope of the work required for remote debugging is considerable – the debugger must be part of the JVM, it must be exposed through a port in the app service, there must be tooling written that can communicate with this debugger, VS Code will provide a visual interface for remote debugging, etc. It seems like your work cuts across a number of different layers – it must be difficult to line everyone up and get a shared vision of this feature. On top of this, Microsoft has engineering teams in a number of different geographies – how does working on something so complex across so many layers in many geographies work?
There is no magic 🙂

Yes there has been ongoing communications among different teams, the conversations are all based on the BI data and customer feedback. When you put the customers’ requirement in front of the table, you’re more easily to get support from your partner teams.

The VS Code team is in Zurich, Azure Application Platform and Azure Functions team are in Redmond, the Java Debugger team is in Shanghai. Some of the team members need to fight against the jetlag and travel abroad, and some need to switch their working hours so we can have conference meetings across the ocean.

[Jonathan Note: There is a blog post on using VS Code to debug Java applications that might be of interest to readers, as well as a recent article on the latest improvements].

What does a normal day look like for you? Are you able to dive deeply into coding, is there a lot of planning / communication required?
I actually spend a lot of time with customers.

One big difference in the last couple years at Microsoft is the faster release cadence. In the old days, we used to have new release every 3 years, and now it is 3 weeks. We’ve keep a close eye on the feedback from our users, the number of downloads, error reporting, etc. This gives us chance to bring new features to the market as soon as possible, and we can adjust the direction / priority based on the results.

Thanks so much for your time! Do you have any other final words that you want to share with the community?
Yes, I would love to hear how people are using Content Assist / IntelliSense while writing in Java.

What are the most annoying things and what are the features you would love to have. My team is thinking to make improvements in this area, let us know what you would love to have 🙂

We’re looking for crazy ideas that push Content Assist / IntelliSense to a new level using machine learning and AI.

Take one example – developers would spend a considerable amount of time searching for code samples and follow common patterns while using certain API, we want to see whether developers would find it helpful if the IDE could help to generate a code snippet based on the API being used.

Another example is the async feature in Java, will people feel excited if there is a tool to automatically convert sync code to async, or vice versa?

[Jonathan Note: Please leave any feedback you might have for Reiley as a comment below, or else feel free to email me and I will forward it on to Reiley].

Thanks Reiley!
